Photovoltaic Small Foldable Solar Panel PET Laminated Appearance Consistency

Product Categories
Shenzhen JYG New Energy Co., Ltd.
Contact Now

Photovoltaic Small Foldable Solar Panel PET Laminated Appearance Consistency

  • 1
  • 2
  • 3

Brand Name : JYG

Model Number : JYG-2W-P

Certification : CE,ROHS

Place of Origin : CHINA

MOQ : 1

Price : negotiable

Payment Terms : Western Union, , T/T, L/C

Supply Ability : Mini custom solar panels

Delivery Time : 7-15days

Packaging Details : standard export package 2pcs/carton

Name : photovoltaic small PET laminated 12v 1W 2W 3W 4W 5W PV solar panel, customized small solar module for power bank

Material : Polycrystalline

Output peak voltage : 2W

Max power voltage : 6V can be customized

Max power current : 0.33A

Application : home system.outdoor travel,camper

Warranty : 5years

Contact Now

photovoltaic small PET laminated 12v 1W 2W 3W 4W 5W PV solarpanel, customized small solar module for power bank

Glass

> Antireflective glass

> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Service life is as long as 30 years

Solar Cell

> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module

> Anti-PID

Frame

> Conventional frame
> Yellow or green frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength

Junction box

> Conventional standalone edition and engineering custom edition
> IP67 protection level

> Long service life
flex solar panel

Solar-cells
Poly-crystalline 156*156mm
Max Power(W)
1
2
3
5
10
Voltage at pmax(Vmp)
6
6
6
9
17.8
Current at pamx(Imp)
0.16
0.32
0.48
0.56
0.56
Open-circuit voltage(Voc)
7.3
7.3
7.3
11.2
22.6
Short-circuit current(Isc)
0.18
0.36
0.54
0.65
0.58
Module efficient
9
8.5
9
10
10.3
Temperature coefficient of pmax
-0.45%/℃
Temperature coefficient of Voc
-0.34%/℃
Temperature coefficient of Isc
0.05%/℃
Nominal perating cell temperature
45±2 ℃
Cable lenght(mm)
70
70
70
70
70
Dimensions(mm)
135*82*10
168*140*17
238*140*17
259*192*17
345*285*18
Net Weight(Kg)
0.132
0.216
0.37
0.53
1.1
Fire rating
Class C
1 Years Workmanship Warranty
5 Years Linear Power Output Warranty

Photovoltaic Small Foldable Solar Panel PET Laminated Appearance ConsistencyPhotovoltaic Small Foldable Solar Panel PET Laminated Appearance Consistency
